1530 CO2 Laser Cutters

1530 Laser Cutting Machine Cutter for Aluminum Plate Cutting Metal Gear Parts Steel Crafts Cutting

Highlights

  • Maximum Dead Speed: 4000mm/min
  • Maximum Processing Speed: 4000mm/min
  • Mesa Structure: Proximate Matter
  • Engrave Instruction G code: *U00*MMG*NC
  • Bilateral drive with rack and pinion, with the characteristics of stability, good rigidity, advanced oil injection system to ensure the machine's high efficiency and stability.
  • CE
  • iSET
  • EMC²
  • RoHS
Request A Quote

Product Parameters

1 2
Model No. ZX-1325 ZX-1530
Laser Power/W 60W/80W/100W/130W/150W 1000W/1500W/2000W/3000W
Working Area 1300*2500mm 1500*3000mm
Cutting Speed 1-300mm/s 1-150mm/s
Engraving Speed 1-1024mm/s Depend on laser power
Cutting Depth 0-2mm(Depend on materials) 0-30mm(Depend on materials)
Engraving Depth 0-20mm(Depend on materials) Depend on laser power
Power Supply AC220V/110V 50HZ AC380V/50HZ
Laser Type Sealed CO2laser Tube Fiber Laser Generator
Software Supported WindowsXP/WIN7/WIN10 CypCut control system
Worktable Multifunctional work table Cast Aluminum Beam
Cooling Water Cooling Water Cooling
Product Dimensions 3200*2010*1140mm 4500*2200*1500mm
Product Weight/Kg 840 3200
